Theme Layer of Liferay Screens for iOS

The Theme Layer lets developers set a Screenlet’s look and feel. The Screenlet property themeName determines the Theme to load. This can be set by the Screenlet’s Theme Name field in Interface Builder. A Theme consists of a view class for Screenlet behavior and an XIB file for the UI. By inheriting one or more of these components from another Theme, the different Theme types allow varying levels of control over a Screenlet’s UI design and behavior.

Figure 1: The Theme Layer of Liferay Screens for iOS.

There are several Theme types:

• Default Theme: The standard Theme provided by Liferay. It can be used as a template to create other Themes, or as the parent Theme of other Themes. Each Theme for each Screenlet requires a View class. A Default Theme’s View class is named MyScreenletView_default, where MyScreenlet is the Screenlet’s name. This class is similar to the standard ViewController in iOS; it receives and handles UI events by using the standard @IBAction and @IBOutlet. The View class usually uses an XIB file to build the UI components. This XIB file is bound to the class.

• Child Theme: Presents the same UI components as the parent Theme, but can change the UI components’ appearance and position. A Child Theme specifies visual changes in its own XIB file; it can’t add or remove any UI components. In the diagram, the Child Theme inherits from the Default Theme. Creating a Child Theme is ideal when you only need to make visual changes to an existing Theme. For example, you can create a Child Theme that sets new positions and sizes for the standard text boxes in Login Screenlet’s Default Theme, but without adding or overwriting existing code.

• Full: Provides a complete standalone theme. It has no parent Theme and implements unique behavior and appearance for a Screenlet. Its View class must extend Screens’s BaseScreenletView class and conform to the Screenlet’s view model protocol. It must also specify a new UI in an XIB file. Refer to the Default Theme for an example of a Full Theme.

• Extended: Inherits the parent Theme’s behavior and appearance, but lets you change and add code to both. You can do so by creating a new XIB file and a custom View class that extends the parent Theme’s View class. In the diagram, the Extended Theme inherits the Full Theme and extends its Screenlet’s View class. Refer to the Flat7 Theme for an example of an Extended Theme.

Themes in Liferay Screens are organized into sets that contain Themes for several Screenlets. Liferay’s available Theme sets are listed here:

• Default: A mandatory Theme set supplied by Liferay. It’s used if the Screenlet’s themeName isn’t specified or is invalid. The Default Theme uses a neutral, flat white and blue design with standard UI components. For example, the Login Screenlet uses standard text boxes for the user name and password fields, but uses the Default Theme’s flat white and blue design.

• Flat7: A collection of Themes that use a flat black and green design, and UI components with rounded edges. They’re Extended Themes.

• Westeros: The Theme for the Bank of Westeros sample app.

For more details on Theme creation, see the tutorial series Creating iOS Themes.
